Sea Bird (DP1 AHTS, 5000BHP) во времена управления Tidewater Marine под названием Errington Tide следует к пункту назначения АИС "RDR field".
ГД 2, 3657 кВт
ДГ 2, CAT 3406 DITA 2x340кВт
Место постройки ASL MARINE BATAM - BATAM, INDONESIA
Нажмите для раскрытия...
Тип идентификатора
IMO
Идентификатор
9422976
Расположение судна
Гвинейский залив, Нигерия
Главный двигатель
NIIGATA 6MG28HX
Оператор
TIDEWATER MARINE LLC
Собственник
TIDEWATER BOATS LTD
Год постройки
2009
Orion
Некоторые данные ТБС Sea Bird, ранее Errington Tide:

Principal Particulars
Official NumberSLR10622
Call Sign9LU2635
IMO Number9422976
Year Of Built2009
Port of RegistryFree Town
BuilderPT ASL SHIPYARD INDONESIA - BATAM
FlagSierra Leone
ClassRINA
NotationDYNAPOS DP1 Offshore Support Vessel - supply - anchor handling ; tug ; fire-fighting ship - 1 ; unrestricted navigation

Dimension
Length Overall60.1 M
Depth Moulded
Beam, moulded		6 M
16 M
Lightship / Max Draft2.7 / 5.1M
Freeboard Darft0.9 M
Minimum Height24.8 M
Deadweight / Displacement1,844 / 3,347t
Clear Deck Space393 M²
Deck Strength5.0 t/M²

Machinery
Main Engine2 x NIIGATA 6MG28HX 2 x 1864 KW
Gear2 x HITACHI NICO 3.09:1
PropellersKAMOME CPP with Kort Nozzles
Rudders2 x HIGH LIFT KAMOME K7
Primary Generators2 x 320 kW 440 V 60 Hz / CAT 3406 DITA
Secondary Generators2 x 750 kW 440 V 60 Hz / MAIN ENGINES
Emergency Generators72 kW 440 V 60 Hz / CAT C4.4
Bow ThrusterKAMOME TCB90DHN / 506kW Electric Motor
Total Thrust Max7.7 mt 8.5 st
Stern ThrusterKAMOME TCB90DHN / 506kW Electric Motor
Total Thrust Max7.7 mt 8.5 st

Performance
Bollard Pull61 t
Speed - Average/ Fuel Consumption10 knots / 6 M3/ 24 H
Speed- Maximum / Fuel Consumption12.5 knots / 11 M3 / 24 H
Fuel Consumption in Port ( Eng Stop)0.9 M3
Fuel Consuption (Eng Run)1.9 M3 / 24H

Towing And Deck Equipment
WinchWATER FALL DD
ModelPLIMSOLL
Stabilization SystemBilge Keels
Rescue ZoneYes
Rescue BoatYes
Water Maker5T/DAY
Reefer Sockets2x440v, 32A
Anchors (2)3505 lbs HHP
Chain (per side)1444 ft of 1.57 in
WindlassPLIMSOLL 10T @ 10 M/MIN
Capstans ( 2 )PLIMSOLL HVC05/380S
Line Pull11,025 lbs
Line Pull330,690 lbs
AH drum Capacity1200 M of 60 in
Tow drum Capacity1200 M of 60 in

Cargo Capacities
Deck Cargo800.0 T
Fuel Oil506.6 M³
Potable Water161.2 M³
Fresh Water160.2 M³
Drill / Ballast Water574.0 M³
Drill / Ballast Water574.0 M³
Bulk Tanks ( 4 ) Total170.0 M³
Liquid Mud (21 lbs/gal)484.8 M³
Walk In Freezer / Cooler10 / 12 M³
Lube Oil7.2 M³
Fire Fighting Foam8.0 M³
Oil Dispersant Capacity8.0 M³
Mud AgitationYes
Mud RecirculationYes

Navigation & Communication
Radar2 x Furano
RadioVHF (3) SSB (1) Furano
Depth Sounder1 Furano
Magnetic Compass1
Gyro Compass2 STD22
GPS1 Furano
DGPS2 sea star Fugro
Wind Speed Indicator2
Dynamic PositioningDP1 CLASSED Kongsberg

Accommodation
Berth cabins1 X 4
Berth cabins2 X 5
Berth cabins4 X 3
Crew12
Passengers22
Galley Seating24
Dayroom/Lounge10 ,1 Seats
Certified to Carry26
HospitalYes

Оригинальный PDF http://www.ships-boats.com.eg/img/Sea - Brid.pdf
