BOURBON LIBECCIO

Orion · 4 Май 2025

FSIV tech specs:
DIMENSIONS

Length overall:.............................................................................53,37
Breadth moulded:.........................................................................9,76 m
Depth:..............................................................................................3,96 m
Draft:................................................................................................2,13
Light displacement: …………………………………219
Displacement at full load: ……………………………521 mt
Gross tonnage:...............................................................................454
Net tonnage:…..............................................................................136

CAPACITIES

Deck area:.............................. (30,50 x 7,63) 242 m2 @ 2,5 mt/m2
Deck cargo:........................................................................................223 t
Fuel oil:.....................................................................................142,80 m3
Drill water:................................................................................112,50m3
Fresh water:.................................................................................7,60 m3
Gray water:...................................................................................0,95 m3
Bilge:..............................................................................................1.90 m3
Sewage:.........................................................................................0.90 m3

DELIVERY RATES

Fuel oil:..........................................................................80 m3/h at 6 bars
Drill water:....................................................................80 m3/h at 6 bars

ACCOMMODATIONS

Accommodations for:.....................................................................8 pers.
1 man cabins:.............................................................................................4
2 man cabins:.............................................................................................2
Mess / Day room, Laundry, Galley, stores
Fully air conditonned
Fitted with 80 individual passenger seats in 1 lounge.
Crew: 8 persons.

PROPULSION - MACHINERY

Main engines: (total 7,500 bhp)....................................4 x 1,875 bhp.
Propellers:...........................4 x 54’’ diameter with 4 blades 54’’pitch.
Bow tunnel thruster:.............................................................1x 200 bhp.
Auxiliary generators:.............................................................2 x 148 KW.
1 fuel oil purifier.

SPEED / CONSUMPTION

Maximum speed (100%):....................................20.5 m3/day 30 knots
Full loaded speed :................................................22,7 m3/day 20 knots

DECK EQUIPMENT

Anchor windlass:.................................1 hydraulic with 100 lb anchor.
Tuggers: ............................................................................................2 x 5 t.
Fire-fighting: 2 monitors of 1,260 m3/h each and 2 pumps of 1,200 m3/h each.
